MODEL NAME		RATED CURRENT	RATED VOLTAGE	TEST VOLTAGE (@ 60 Sec)		LEAKAGE CURRENT	WEIGHT
37T (1 Stage)	37T (2 Stage)	(A)	3P 3L (V)	L-L (W/OUT R)	L-GND	60Hz, 690V	1 Stage (kg)	2 Stage (kg)
37T250-N11V	37T250-N22V	250	690Vac	3.4kVdc	3.4kVdc	1 Stage : 43 mA max. 2 Stage : 86 mA max.	3.2	4.5
37T300-N11V	37T300-N22V	300					3.2	4.5
37T400-N11V	37T400-N22V	400					4.5	6.5
37T500-N11V	37T500-N22V	500					5	7
37T600-N11V	37T600-N22V	600					5	7
37T800-N11V	37T800-N22V	800					8.5	12
37T1000-N11V	37T1000-N22V	1,000					8.5	12
37T1600-N11V	37T1600-N22V	1,600					13.5	19
37T2000-N11V	37T2000-N22V	2,000					15	21
37T3000-N11V	37T3000-N22V	3,000					18	24
37T3500-N11V	37T3500-N22V	3,500					21	27
37T4000-N11V	37T4000-N22V	4,000					24	30
