MODEL NAME		RATED CURRENT	RATED VOLTAGE	TEST VOLTAGE (@ 60 Sec)		LEAKAGE CURRENT	WEIGHT
32 Series	35 Series	(A)	AC (V)	L-L (W/OUT R)	L-GND	32 : 250V / 35: 500V	(kg)
32U010-N21	35U010-N21	10	32 Series : 250V 35 Series : 500V	2.15kVdc	3kVac	32 Series : 22 mA max. 35 Series : 43 mA max.	1.2
32U020-N21	35U020-N21	20					1.3
32U030-N21	35U030-N21	30					1.3
32U040-N21	35U040-N21	40					1.3
32U050-N31	35U050-N31	50					2.0
32U060-N31	35U060-N31	60					2.0
32U080-N31	35U080-N31	80					3.5
32U100-N31	35U100-N31	100					3.5
32U120-N31	35U120-N31	120					4.7
32U150-N31	35U150-N31	150					4.7
32U180-N31	35U180-N31	180					4.7
32U200-N31	35U200-N31	200					4.7
